Specification & Description
Basic Information |
||
Supported CPU |
Intel Socket LGA1700 for 12th Gen Intel Core, Pentium Gold and Celeron ProcessorsSupports Intel Turbo Boost Technology 2.0 and Intel Turbo Boost Max Technology 3.0 |
|
BIOS |
128 Mb Flash ROM, UEFI AMI BIOS |
|
Form Factor |
microATX24.4cm x 21.1cm |
|
Audio |
Realtek 7.1 Surround Sound High Definition Audio CODEC*– Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking– Supports up to 24-Bit/192 kHz playback”Audio Features– Audio Shielding– Premium audio capacitors– Dedicated audio PCB layers* A chassis with an HD audio module in the front panel is required to support 7.1 Surround Sound audio output. |
|
Expansion Slots |
||
PCI |
Intel 12th Gen Processors1 x PCIe 4.0/3.0 x16 slotIntel B660 Chipset2 x PCIe 3.0 x1 slots |
|
Memory |
||
Type |
DDR4 |
|
Slots |
2 x DIMM |
|
Supported Memory |
5333(OC)/ 5000(OC)/ 4800(OC)/ 4600(OC)/ 4400(OC)/ 4266(OC)/ 4000(OC)/ 3733(OC)/ 3600(OC)/ 3466(OC)/ 3400(OC)/ 3333(OC)/ 3200/ 3000/ 2933/ 2800/ 2666/ 2400/ 2133 Non-ECC, Un-buffered MemoryDual Channel Memory ArchitectureSupports Intel® Extreme Memory Profile (XMP) |
|
Maximum Memory |
64GB |
|
Graphics |
||
Graphics |
1 x D-Sub port1 x HDMI port (Support 4K@60Hz as specified in HDMI 2.1) |
|
Connector & Ports |
||
HDMI |
1 x HDMI port |
|
D-Sub (s) |
1 x D-Sub port |
|
USB (s) |
4 x USB 3.2 Gen 1 ports (4 x Type-A)2 x USB 2.0 ports (2 x Type-A)Front USB:Total 6 ports1 x USB 3.2 Gen 1 header supports additional 2 USB 3.2 Gen 1 ports2 x USB 2.0 headers support additional 4 USB 2.0 ports |
|
LAN Port (s) |
1 x Realtek 1Gb Ethernet |
|
Supported Storage |
Supports 2 x M.2 slots and 4 x SATA 6Gb/s portsTotal supports 2 x M.2 slots and 4 x SATA 6Gb/s portsIntel 12th Gen ProcessorsM.2_1 slot (Key M), type 2242/2260/2280– Intel 12th Gen processors support PCIe 4.0 x4 mode.Intel B660 ChipsetM.2_2 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4)4 x SATA 6Gb/s ports |
|
Audio |
3 x Audio jacks |
|
Internal I/O Ports |
Fan and Cooling related1 x 4-pin CPU Fan header1 x 4-pin Chassis Fan headerPower related1 x 24-pin Main Power connector1 x 8-pin +12V Power connectorStorage related2 x M.2 slots (Key M)4 x SATA 6Gb/s portsUSB1 x USB 3.2 Gen 1 header supports additional 2 USB 3.2 Gen 1 ports2 x USB 2.0 headers support additional 4 USB 2.0 portsMiscellaneous1 x RGB header1 x Clear CMOS header1 x COM Port header1 x Front Panel Audio header (AAFP)1 x S/PDIF Out header1 x Speaker header1 x 10-1 pin System Panel header |
|
TPM (Trusted Platform Module ) |
1 x SPI TPM header (14-1pin) |
|
Warranty Information |
||
Manufacturing Warranty |
3 years |
|
Others |
||
Special Features |
ASUS 5X PROTECTION III– DIGI+ VRM– LANGuard– Overvoltage Protection– SafeSlot Core– Stainless-Steel Back I/OASUS Q-Design– Q-DIMM– Q-SlotASUS EZ DIY– ProCoolASUS Thermal Solution– VRM heatsink designASUS Lighting Control-RGB header |
|
Bundled Software |
ASUS Exclusive SoftwareArmoury CrateAI Suite 3– Performance And Power Saving UtilityTurboV EVOEPUDIGI+ VRMFan XpertASUS CPU-ZNorton Anti-virus software (Free Trial version)WinRARUEFI BIOSASUS EZ DIY– ASUS CrashFree BIOS 3– ASUS EZ Flash 3– ASUS UEFI BIOS EZ Mode |
