Asus PRIME H410M-CS DDR4 10th Gen Intel LGA1200 Socket Mainboard
৳ 0.00
Let’s check the overview
-
Model – Asus PRIME H410M-CS
-
CPU Sockets – LGA1200
-
Chipset – Intel H410 Chipset
-
Generation – 10th Gen
-
Memory Channel – Dual channel
-
Audio Chipset – Realtek ALC887
-
VGA Port – 1
Specification & Description
Asus PRIME H410M-CS DDR4 10th Gen Intel LGA1200 Socket Motherboard
Are you Worried to Know Asus Prime H410M-CS Motherboard Price in Bangladesh? let’s Discuss the Price of the Asus Prime H410M-CS Motherboard. The Asus Prime H410M-CS Motherboard with Intel Socket 1200 for 10th Gen Intel Core, Pentium Gold, and Celeron Processors. It comes with a Realtek RTL8111H LAN, 2 x DIMM slots with Max. 64GB memory capacity, 6 x SATA3 ports, and 2 x M.2 slots for storage expansion. This Asus Prime H410M-CS Motherboard also supports ASUS Aura Sync to sync RGB lighting with the other compatible devices. The Asus Prime H410M-CS Motherboard is a System Builder’s motherboard offering an attractive array of features, including quality components and reliable performance. Based on the Intel B360 chipset, this ATX form-factor mainboard supports 10th Generation Intel Core processors and LGA1151 socket motherboards. The board is built with IR digital PWM controller for efficient power delivery and thermal control. It also has dual M.2 slots with M Key that supports PCIe Gen3 x4 up to 32Gb/s speed. The Asus Prime H410M-CS Motherboard delivers a measurable performance boost over the previous generation. It is built with an ATX form factor, has 4 x DDR4 dual-channel slots, and supports Intel S1200 series chipsets. Asus Prime H410M-CS Motherboard with 4xDIMM slots supports 2133/2400MHz DDR4 memory and up to 64GB. Asus Prime H410M-CS Motherboard is a mainboard with an Intel H410 chipset, supporting 10th Generation Intel Core, Pentium Gold, and Celeron Processors. This mainboard supports DDR4 2133 MHz memory and two DIMM slots offering up to Max. 64GB memory capacity.
What is The Asus PRIME H410M-CS DDR4 10th Gen Intel LGA1200 Socket Mainboard Price In Bangladesh?
The latest price of Asus Prime H410M-CS Motherboard is ৳ 7,700 . You can buyAsus Prime H410M-CS Motherboard best price from samanta Computer or visit any of our showrooms.
Specifications
| Basic Information | ||
| Supported CPU | Intel Socket 1200 for 10th Gen Intel Core, Pentium Gold and Celeron Processors Supports Intel 14 nm CPU Supports Intel Turbo Boost Technology 2.0 and Intel Turbo Boost Max Technology 3.0 |
|
| Chipset | Intel H410 | |
| BIOS | 128 Mb Flash ROM, UEFI AMI BIOS | |
| Form Factor | mATX Form Factor: 8.9 inch x 8.0 inch ( 22.6 cm x 20.3 cm ) | |
| Expansion Slots | ||
| PCI | Intel 10th Gen Processors: 1 x PCIe 3.0 x16 (x16 mode) Intel H410 Chipset: 2 x PCIe 3.0 x1 |
|
| M.2 Socket | 1 x M.2 Socket 3, with M Key, type 2242/2260/2280 storage devices support (SATA & PCIE 3.0 X2 mode) | |
| Memory | ||
| Type | Dual Channel Memory Architecture | |
| Slots | 2 x DIMM | |
| Supported Memory | Supports 2933/2800/2666/2400/2133 MHz Non-ECC, Un-buffered Memory Supports Intel Extreme Memory Profile (XMP) OptiMem |
|
| Maximum Mamory | 64GB | |
| Graphics | ||
| Graphics | Integrated Graphics Processor 1 x D-Sub 1 x HDMI 1.4b |
|
| Connector & Ports | ||
| HDMI | 1 x HDMI 1.4b | |
| USB (s) | Rear USB Port ( Total 4 ) 2 x USB 3.2 Gen 1 port(s)(2 x Type-A) 2 x USB 2.0 port(s)(2 x Type-A) Front USB Port ( Total 6 ) 2 x USB 3.2 Gen 1 port(s) 4 x USB 2.0 port(s) |
|
| LAN Port (s) | Realtek RTL8111H | |
| Supported Storage | Total supports 1 x M.2 slots and 4 x SATA 6Gb/s ports Intel H410 Chipset : 1 x M.2 Socket 3, with M Key, type 2242/2260/2280 storage devices support (SATA & PCIE 3.0 X2 mode) 4 x SATA 6Gb/s port(s) |
|
| Audio | Realtek ALC887 7.1-Channel High Definition Audio CODEC – Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking, up to 24-Bit/192kHz playback Audio Feature: – LED-illuminated design – Audio Shielding – Dedicated audio PCB layers – Premium Japanese audio capacitors |
|
| Internal I/O Ports | 1 x CPU Fan connector(s) 1 x Chassis Fan connector(s) 1 x USB 3.2 Gen 1(up to 5Gbps) connector(s) support(s) additional 2 USB 3.2 Gen 1 port(s) 2 x USB 2.0 connector(s) support(s) additional 4 USB 2.0 port(s) 1 x M.2 Socket 3 with M Key, type 2242/2260/2280 storage devices support (SATA & PCIE 3.0 X2 mode) 1 x COM port(s) connector(s) 4 x SATA 6Gb/s connector(s) 1 x S/PDIF out header(s) 1 x 24-pin EATX Power connector(s) 1 x 8-pin EATX 12V Power connectors 1 x Front panel audio connector(s) (AAFP) 1 x Clear CMOS jumper(s) 1 x System panel connector 1 x Speaker connector |
|
| D-Sub (s) | 1 x D-Sub | |
| Warranty Information | ||
| Manufacturing Warranty | 03 Years | |
| Others | ||
| Special Features | Software Features: ASUS Exclusive Software Armory Crate AI Suite 3 – Performance And Power Saving Utility TurboV EVO EPU Digi+ VRM Fan Xpert – EZ update ASUS CPU-Z AI Charger DAEMON Tools Norton Anti-virus software (Free Trial for 60 days) WinRAR UEFI BIOS ASUS EZ DIY – ASUS CrashFree BIOS 3 – ASUS EZ Flash 3 – ASUS UEFI BIOS EZ ModeASUS Special Features: ASUS 5X PROTECTION III – ASUS DIGI+ VRM – ASUS LANGuard – ASUS Overvoltage Protection – ASUS SafeSlot Core – ASUS Stainless-Steel Back I/O ASUS Q-Design – ASUS Q-DIMM – ASUS Q-Slot ASUS Thermal Solution – Aluminum heatsink design |
|
