Specification & Description
About This Product
Asus TUF GAMING B460-PRO (WI-FI)
The ASUS TUF GAMING B460-PRO Wi-Fi LGA 1200 ATX Motherboard is designed around the Intel B460 chipset, supporting 10th Gen Intel Core, Pentium Gold, and Celeron processors with an LGA 1200 socket. You can also connect to the internet wirelessly via Wi-Fi 6 (802.11ax). It has four memory slots supporting up to 128GB of dual-channel DDR4 RAM, which can run up to 2933 MHz. There are six SATA III ports and two M.2 slots for storage. This motherboard features an ATX form factor, allowing for use in mid-tower and full tower cases. Other integrated features include Intel I219-V Gigabit Ethernet and Realtek ALC S1200A 8.1-channel HD audio.
Intel B460 Chipset
This motherboard features the Intel B460 Chipset and the Intel LGA Socket 1200, making it ready for 10th Gen Intel Core processors.
Wi-Fi 6 (802.11ax)
This motherboard features the Intel Wi-Fi 6 AX200 module, which is compatible with the 802.11ax standard, which has a theoretical peak of up to 2.4 Gb/s. Pair this motherboard with a compatible Wi-Fi 6 router to fully experience the potential networking speeds of Wi-Fi 6.
ASUS OptiMem Technology
ASUS OptiMem technology carefully maps memory signal pathways across different PCB layers to reduce vias and adds shielding zones that significantly reduce crosstalk. This allows for improved memory stability and compatibility, lower memory latencies at equivalent voltages, and improved memory frequency margin.
The dual M.2 slots support data transfer rates of up to 32 Gb/s via PCIe 3.0 x4 bandwidth, enabling quicker boot times and app load times with OS or application drives.
Armoury Crate is a software utility designed to give you centralized control of supported products. From a single intuitive interface, Armoury Crate allows you to easily customize RGB lighting and effects for every compatible device. The software also provides control of settings for ASUS products, including keyboard and mouse preferences. Armoury Crate can even provide dedicated product registration and help from the ASUS community.
SafeSlot Core is the ASUS-exclusive PCIe slot. The fortified design anchors to the motherboard by a special hook. SafeSlot Core provides 1.6 times the retention and 1.3 times the shearing resistance than standard expansion slots.
Model – Asus TUF GAMING B460-PRO (WI-FI), CPU Sockets – LGA1200, Chipset – Intel B460, Supported CPU – 10th Gen Intel Core and Pentium Gold / Celeron processors, Generation – 10th, Memory Type – DDR4, Memory MHz – 2933/ 2800/ 2666/ 2400/ 2133MHz, Memory Channel – Dual Channel, Memory Slot – 4, Memory Max. – 128GB, Optane Memory Support – Yes, Graphic – Integrated Graphics, Multi-GPU Support – 2-Way AMD CrossFireX, PCI Express Slot – 1 x PCIe 3.0 x16 (x16 mode), 1 x PCIe 3.0 x16 (x4 mode), 3 x PCIe 3.0 x1, Storage Interface – 6Gb/s, M.2 Slot – 2 x M.2 Socket 3 (1 x M.2 (M key, type 2242/2260/2280 storage devices support (SATA & PCIE 3.0 x 4 mode)), 1 x M.2 (M key, type 2242/2260/2280/22110 storage devices support (PCIE 3.0 x 4 mode))), LAN Chipset – Intel I219-V, Audio Chipset – Realtek ALC S1200A, Audio Channel – 8-Channel, WiFi – Yes, WiFi Technology – Intel Wi-Fi 6 AX200, 2×2 Wi-Fi 6 (802.11 a/b/g/n/ac/ax) support 1024QAM/OFDMA/MU-MIMO, Supports up to 2.4Gbps max data rate, Supports dual band frequency 2.4/5 GHz, Supports channel bandwidth: HT20/HT40/HT80/HT160, Supports PCIe interface, Bluetooth – Bluetooth 5.1, USB Port – 2 x USB 3.2 Gen 2 Type-A, 6 x USB 3.2 Gen 1 Type-A, 4 x USB 2.0, VGA Port – No, DVI Port – No, HDMI Port – 1, DisplayPort (DP) – No, IDE Port – No, SATA Port – 6 x SATA, BIOS Type – 1 x 128 Mbit Flash ROM, BIOS Model – UEFI AMI BIOS, FireWire – No, CrossFire Support – Yes, Sli Support – No, RaidSupport – 0, 1, 5, 10, Thunderbolt – No, TPM Port – No, COM Port – Yes, RGB Support – Yes, RGB Sync – Aura Sync, RGB Connector – 2 x Aura RGB Strip Headers, Form Factor – ATX, Supported Operating System – Windows 10, Special Features – ATX gaming motherboard with dual M.2, 8 power stages, Intel WiFi 6, HDMI, DisplayPort, SATA 6Gbps, USB 3.2 Gen 2 port, and Aura Sync RGB Lighting, Intel LGA 1200 socket Ready for 10th Gen Intel Core processors, Enhanced power solution, 6+1+1 power stages, military-grade TUF components, and Digi+ VRM for maximum durability, Comprehensive cooling, VRM heatsink, M.2 heatsink, PCH heatsink, hybrid fan headers and Fan Xpert 4, Made for online gaming, Intel WiFi 6, Intel Ethernet Connection I219-V, TUF LANGuard and TurboLAN technology, Realtek S1200A codec, Pristine audio quality with unprecedented 108 dB signal-to-noise ratio for stereo line out and 103 dB SNR for line in, Intel Rapid Storage Technology supports, Intel Optane Memory Ready, Others – 1 x DisplayPort 1.4, 2 x Chassis Fan connector(s), 1 x AIO_PUMP connector, 1 x Addressable Gen 2 header(s), 1 x Front panel audio connector(s) (AAFP), 1 x Clear CMOS jumper(s), 1 x System panel connector, 1 x COM port header, 1 x ASUS Wi-Fi Module, 3 x Audio jack(s), Wireless Data Network: Intel Wi-Fi 6 AX200, Bluetooth 5.1, Warranty – 3 Year, Country of Origin – Taiwan, Made in/ Assemble – China
