Gigabyte X570 Aorus Pro (Wi-Fi 6) DDR4 AM4 Socket AMD Mainboard

Gigabyte X570 Aorus Pro Wi-Fi (6) DDR4 AM4 Socket AMD Mainboard

৳ 24,000.00

Let’s check the overview

Model: Gigabyte X570 Aorus Pro Wifi
Chipset: AMD X570
CPU: AMD Ryzen Socket AM4
Memory: 4 x DDR4, Max 128 GB
Supports SLI and CrossFire

অর্ডার করার পূর্বে কাস্টমার কেয়ার থেকে পণ্যের স্টক ও ডেলিভারী সম্পর্কে জেনে নেয়ার জন্য অনুরোধ করা যাচ্ছে। প্রযুক্তি পণ্যের মূল্য অস্থিতিশীল হওয়ার কারনে যেকোনো মুহূর্তে যেকোনো প্রযুক্তি পণ্যের মূল্য পরিবর্তন হতে পারে। চলুন সাপোর্ট এ যোগাযোগ করি: Live || 01723-570189(10AM - 8PM)

SKU: #SS2485C Categories: Gigabyte AMD, Motherboard Tag: Gigabyte X570 Aorus Pro (Wi-Fi 6) DDR4 AM4 Socket AMD Mainboard

Specification & Description

Gigabyte X570 Aorus Pro WiFi 6 AMD Mainboard

About This Product

Gigabyte X570 Aorus Pro WiFi 6 AMD Mainboard: Model – Gigabyte X570 Aorus Pro WiFi, CPU Sockets – AM4, Chipset – AMD X570, Supported CPU – AMD Ryzen 2nd and 3rd Generation / Ryzen with Radeon Vega Graphics Processors, – 128GB, Optane Memory Support – No, Graphic – Onboard Graphics, Multi-GPU Support – NVIDIA Quad-GPU SLI and 2-Way NVIDIA SLI, AMD Quad-GPU CrossFire and 2-Way AMD CrossFire, PCI Express Slot – 3rd Generation supporting PCIe 3.0 and running at x8 (PCIEX16), Storage Interface – 6Gb/s, M.2 Slot – 2 x M.2 Socket 3 (type 2242/2260/2280/22110 SATA and PCIe 4.0 /3.0 x4/x2 SSD support),HDMI Port – 1, DisplayPort (DP) – No, IDE Port – No, SATA Port – 6 x SATA, BIOS Type – 2 x 128 Mbit flash,

BIOS Model – AMI UEFI BIOS, BIOS Version – PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0, FireWire – No, CrossFire Support – Yes, Sli Support – Yes, RaidSupport – 0,1,10, Thunderbolt – No, TPM Port – Yes, COM Port – No, RGB Support – Yes, RGB Sync – RGB Fusion 2.0, RGB Connector – 2 x RGB LED strip headers, Form Factor – ATX, Supported Operating System – Windows 10, 12+2 Phases IR Digital VRM Solution with PowIRstage, Advanced Thermal Design with Fins-Array Heatsink and Direct Touch Heatpipe, Dual Ultra-Fast NVMe PCIe 4.0/3.0 x4 M.2 with Dual Thermal Guards, Intel WiFi 6 802.11ax 2T2R & BT 5, ALC1220-VB Enhance 114dB(Rear)/ 110dB(Front) SNR in Microphone with WIMA Audio Capacitors, Intel Gigabit LAN with cFosSpeed Internet Accelerator Networking, RGB FUSION 2.0 with Multi-Zone Addressable LED Light Show Design, Supports

Addressable LED & RGB LED Strips, Smart Fan 5 features Multiple Temperature Sensors, Hybrid Fan Headers with FAN STOP, Front & Rear USB 3.2 Gen2 Type-C Header & HDMI 2.0 support, Integrated I/O Shield Armor, 1 x CPU cooler LED strip/RGB LED strip header, 1 x front panel header, 1 x front panel audio header, 1 x Trusted Platform Module (TPM) header, 1 x Clear CMOS jumper, 2 x temperature sensor headers, 1 x Q-Flash Plus button, 2 x SMA antenna connectors (2T2R), 5 x audio jacks, Wireless Communication module: Wi-Fi 802.11a/b/g/n/ac/ax, supporting 2.4/5 GHz Dual-Band, BLUETOOTH 5.0, Warranty – 3 Year, Country of Origin – Taiwan, Made in/ Assemble – China

Specification

Basic Information
Supported CPU	Support for: 3rd Generation AMD Ryzen™ processors/ 2nd Generation AMD Ryzen™ processors/ 2nd Generation AMD Ryzen™ with Radeon™ Vega Graphics processors/ AMD Ryzen™ with Radeon™ Vega Graphics processors
Chipset	AMD X570
BIOS	2 x 128 Mbit flash Use of licensed AMI UEFI BIOS Support for DualBIOS™ PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
Form Factor	ATX Form Factor; 30.5cm x 24.4cm
Audio	Realtek ALC1220-VB codec The back panel line out jack supports DSD audio. High Definition Audio 2/4/5.1/7.1-channel Support for S/PDIF Out
Expansion Slots
PCI	Integrated in the CPU (PCIEX16/PCIEX8): · 3rd Generation AMD Ryzen processors: 1 x PCI Express x16 slot, supporting PCIe 4.0 and running at x16 (PCIEX16) 1 x PCI Express x16 slot, supporting PCIe 4.0 and running at x8 (PCIEX8) · 2nd Generation AMD Ryzen processors: 1 x PCI Express x16 slot, supporting PCIe 3.0 and running at x16 (PCIEX16) 1 x PCI Express x16 slot, supporting PCIe 3.0 and running at x8 (PCIEX8) For optimum performance, if only one PCI Express graphics card is to be installed, be sure to install it in the PCIEX16 slot. The PCIEX8 slot shares bandwidth with the PCIEX16 slot. When using the 3rd Generation AMD Ryzen processors/2nd Generation AMD Ryzen processors, the PCIEX16 slot operates at up to x8 mode. · 2nd Generation AMD Ryzen with Radeon Vega Graphics processors/AMD Ryzen with Radeon Vega Graphics processors: 1 x PCI Express x16 slot, supporting PCIe 3.0 and running at x8 (PCIEX16) Integrated in the Chipset (PCIEX4/PCIEX1): 1 x PCI Express x16 slot, supporting PCIe 4.0/3.0 and running at x4 (PCIEX4) For 3rd Generation AMD Ryzen processors only. 2 x PCI Express x1 slots, supporting PCIe 4.0/3.0 For 3rd Generation AMD Ryzen™ processors only.
M.2 Socket	Integrated in the CPU (M2A_SOCKET): · 3rd Generation AMD Ryzen™ processors: 1 x M.2 connector (Socket 3, M key, type 2242/2260/2280/22110 SATA and PCIe 4.0 x4/x2 SSD support) · 2nd Generation AMD Ryzen™ processors/2nd Generation AMD Ryzen™ with Radeon™ Vega Graphics processors/AMD Ryzen™ with Radeon™ Vega Graphics processors: 1 x M.2 connector (Socket 3, M key, type 2242/2260/2280/22110 SATA and PCIe 3.0 x4/x2 SSD support) Integrated in the Chipset (M2B_SOCKET): 1 x M.2 connector (Socket 3, M key, type 2242/2260/2280/22110 SATA and PCIe 4.0/3.0 x4/x2 SSD support) For 3rd Generation AMD Ryzen™ processors only. 6 x SATA 6Gb/s connectors Support for RAID 0, RAID 1, and RAID 10
Memory
Type	Dual Channel DDR4 Memory Technology
Slots	4 x DDR4 DIMM sockets supporting up to 128 GB (32 GB single DIMM capacity) of system memory
Supported Memory	3rd Generation AMD Ryzen processors: Support for DDR4 4400(O.C.) / 4300(O.C.) / 4266(O.C.) / 4133(O.C.) / 4000(O.C.) / 3866(O.C.) / 3800(O.C.) / 3733(O.C.) / 3600(O.C.) / 3466(O.C.) / 3400(O.C.) / 3333(O.C.) / 3300(O.C.) / 3200 / 2933 / 2667 / 2400 / 2133 MHz memory modules 2nd Generation AMD Ryzen processors/AMD Ryzen with Radeon Vega Graphics processors: Support for DDR4 3600(O.C.) / 3400(O.C.) / 3333(O.C.) / 3200(O.C.) / 2933 / 2667 / 2400 / 2133 MHz memory modules
Maximum Mamory	128 GB
Graphics
Graphics	Integrated Graphics Processor: 1 x HDMI port, supporting a maximum resolution of 4096×2160@60 Hz Support for HDMI 2.0 version, HDCP 2.2, and HDR. Note: For 2nd Generation AMD Ryzen with Radeon Vega Graphics processors/AMD Ryzen with Radeon Vega Graphics processors only.
Max Shared Memory	16 GB
Connector & Ports
HDMI	1 x HDMI port, supporting a maximum resolution of 4096×2160@60 Hz Support for HDMI 2.0 version, HDCP 2.2, and HDR.
USB (s)	Integrated in the CPU: 3 x USB 3.2 Gen 1 ports on the back panel 1 x USB 3.2 Gen 2/Gen 1 Type-A port (red) on the back panel For 3rd Generation AMD Ryzen processors only. Chipset: 1 x USB Type-C port with USB 3.2 Gen 2 support, available through the internal USB header 1 x USB Type-C port on the back panel, with USB 3.2 Gen 2 support 1 x USB 3.2 Gen 2 Type-A port (red) on the back panel 4 x USB 3.2 Gen 1 ports available through the internal USB headers Chipset+USB 2.0 Hubs: 8 x USB 2.0/1.1 ports (4 ports on the back panel, 4 ports available through the internal USB headers)
LAN Port (s)	1 x RJ-45 port
Supported Storage	Integrated in the CPU (M2A_SOCKET): · 3rd Generation AMD Ryzen processors: 1 x M.2 connector (Socket 3, M key, type 2242/2260/2280/22110 SATA and PCIe 4.0 x4/x2 SSD support) · 2nd Generation AMD Ryzen processors/2nd Generation AMD Ryzen with Radeon Vega Graphics processors/AMD Ryzen™ with Radeon™ Vega Graphics processors: 1 x M.2 connector (Socket 3, M key, type 2242/2260/2280/22110 SATA and PCIe 3.0 x4/x2 SSD support) Integrated in the Chipset (M2B_SOCKET): 1 x M.2 connector (Socket 3, M key, type 2242/2260/2280/22110 SATA and PCIe 4.0/3.0 x4/x2 SSD support) For 3rd Generation AMD Ryzen processors only. 6 x SATA 6Gb/s connectors Support for RAID 0, RAID 1, and RAID 10
Audio	5 x audio jacks
Internal I/O Ports	1 x 24-pin ATX main power connector 1 x 8-pin ATX 12V power connector 1 x 4-pin ATX 12V power connector 1 x CPU fan header 1 x water cooling CPU fan header 3 x system fan headers 2 x system fan/water cooling pump headers 2 x addressable LED strip headers 2 x RGB LED strip headers 1 x CPU cooler LED strip/RGB LED strip header 2 x M.2 Socket 3 connectors 6 x SATA 6Gb/s connectors 1 x front panel header 1 x front panel audio header 1 x USB Type-C™ port, with USB 3.2 Gen 2 support 2 x USB 3.2 Gen 1 headers 2 x USB 2.0/1.1 headers 1 x Trusted Platform Module (TPM) header (2×6 pin, for the GC-TPM2.0_S module only) 1 x Clear CMOS jumper 2 x temperature sensor headers 1 x Q-Flash Plus button
Warranty Information
Manufacturing Warranty	03 years
Others
Special Features	Support for APP Center Available applications in APP Center may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications. @BIOS AutoGreen Cloud Station EasyTune Fast Boot Game Boost ON/OFF Charge RGB Fusion Smart Backup Smart Keyboard Smart Survey System Information Viewer USB Blocker Support for Q-Flash Plus Support for Q-Flash Support for Xpress Install
Bundled Software	Norton Internet Security (OEM version) cFosSpeed XSplit Gamecaster + Broadcaster (12 months license)
