Specification & Description
About This Product
MSI MAG B550M MORTAR WIFI
MAG B550M MORTAR WIFI
Powered by AMD Ryzen AM4 processors, the MSI MAG B550M MORTAR WIFI has been toughened with performance essential specifications to outlast enemies. Armed for sustained performance with Wi-Fi, Extended Heatsink Design, 2.5G LAN, Core boost, and Pre-installed I/O Shielding. Equipped with a PCIe 4.0 slot and Lightning M.2 with M.2 Shield Frozr for the latest PCIe device compatibility.
- Support for 3rd Gen AMD Ryzen processors and future AMD Ryzen processors with BIOS update
- Supports dual channel DDR4 memory up to 128 GB (4400 MHz)
- 2.5G LAN with LAN Manager and Wi-Fi 6 AX Solution
- Lightning Fast Game experience: PCIe 4.0, Lightning Gen 4 M.2 with M.2 Shield Frozr, AMD Turbo USB 3.2 GEN 2
- AUDIO BOOST rewards your ears with studio grade sound quality for immersive gaming experiences
- Premium Thermal Solution: Extended heatsink with additional choke thermal pad rated for 7W/mk and PCB with 2oz thickened copper
- Pre-installed I/O Shielding for convenience and protection from electrostatic discharge
|LIGHTNING GEN 4 SOLUTION
Strike fast with MSI Lightning Gen 4 PCI-E. Attach ultra fast PCI-E 4.0 devices and enjoy up to 64GB/s unidirectional transfer bandwidth.
|ENHANCED THERMAL SOLUTION
Extended heatsink that covers the chokes, 7W/mK rated thermal pads, 2oz thickened copper PCB material, and M.2 Shield Frozr keep temperatures in check and let high-performance parts sustain extreme performance.
Core Boost combines a reserved zone of optimized circuits and premium power delivery components to create a highly efficient power system capable of precise current output to the CPU.
|USB TYPE-C READY – Rear IO & Front Case Panel Support
Effortlessly plug in devices with reversible USB Type-C.
|MAXIMIUM DATA TRANSFER WITH 2.5G LAN AND WI-FI 6
Onboard 2.5Gbps Ethernet LAN and 2.4 Gbps Wi-Fi 6 provides incredible network connectivity for gamers. Prioritize latency-sensitive applications with MSI LAN Manager for a superior online experience.
|PRE-INSTALLED IO SHIELDING
Pre-Installed IO Shielding makes handling the motherboard process easier and safer. The design is grounded and protects the IO ports from potential electrostatic discharge damage from the external environment.
Model – MSI MAG B550M MORTAR WIFI, CPU Sockets – AM4, Chipset – AMD B550, Supported CPU – AMD Ryzen 3rd Generation Processors and New Generation AMD Ryzen processors, Memory Type – DDR4, Memory MHz – 4400/ 4266/ 4133/ 4000/ 3866/ 3733/ 3600/ 3466/ 3200/ 3066/ 3000/ 2933/ 2800/ 2667/ 2400/ 2133/ 1866MHz, Memory Channel – Dual Channel, Memory Slot – 4, Memory Max. – 128GB, Optane Memory Support – No, Graphic – Integrated Graphics, Multi-GPU Support – 2-Way AMD CrossFire, PCI Express Slot – 1x PCIe 3.0/ 4.0 x16 slot (PCI_E1), 1x PCIe 3.0 x16 slot (PCI_E4), supports x4 mode, 2x PCIe 3.0 x1 slots, Storage Interface – 6Gb/s, M.2 Slot – 2 x M.2 (1 x M.2 (Supports PCIe 4.0/ 3.0 x4, Supports SATA 6Gb/s, Supports 2242/ 2260/ 2280 storage devices), 1 x M.2 (Supports PCIe 3.0×4, Supports 2242/ 2260/ 2280 storage devices)), LAN Chipset – Realtek RTL8125B, LAN Speed (Mbps) – 2.5Gbps, Audio Chipset – Realtek ALC1200, Audio Channel – 7.1-Channel, WiFi – Yes, WiFi Technology – Intel Wi-Fi 6 AX200, Supports 802.11 a/b/g/n/ac/ax, Supports MU-MIMO TX/RX, 2.4GHz/ 5GHz (160MHz) up to 2.4Gbps., Bluetooth – Bluetooth 5.1, USB Port – 1 x USB 3.2 Gen 2 Type-C, 1 x USB 3.2 Gen 1 Type-C, 1 x USB 3.2 Gen 2 Type-A, 3 x USB3.2 Gen 1 Type-A, 4 x USB2.0, VGA Port – No, DVI Port – No, HDMI Port – 1, DisplayPort (DP) – 1, IDE Port – No, SATA Port – 6 x SATA, DirectX Support – 12, FireWire – No, CrossFire Support – Yes, Sli Support – No, RaidSupport – 0,1,10, Thunderbolt – No, TPM Port – Yes, COM Port – No, RGB Support – Yes, RGB – 1 x 4-pin RGB LED connector, Form Factor – MATX, Supported Operating System – Windows 10, Special Features – Extended Heatsink Design, MSI extended PWM heatsink and enhanced circuit design ensures even high-end processors to run in full speed, M.2 Shield FROZR, M.2 thermal accessory. Keeps M.2 SSDs safe while preventing throttling, making them run faster, Lightning Gen4 solution, The latest Gen4 PCI-E and M.2 solution with up to 64GB/s bandwidth for maximum transfer speed, 2oz Thickened Copper PCB, An enhanced PCB design improves heat dissipation and performance reliability, 2.5G LAN, Onboard 2.5G LAN with LAN manager, delivering the best online gaming experience, WIFI 6, The latest wireless solution supports MU-MIMO and BSS color technology, delivering speeds up to 2400Mbps, Core Boost, With premium layout and fully digital power design to support more cores and provide better performance, DDR4 Boost, Advanced technology to deliver pure data signals for the best gaming performance and stability, Audio Boost, Others – 1 x DisplayPort, 1x 4-pin CPU fan connector, 1x 4-pin water-pump fan connector, 3x 4-pin system fan connectors, 1x Front panel audio connector, 2x System panel connectors, 1x Chassis Intrusion connector, 2x 3-pin RAINBOW LED connectors, 1xTPM module connector, 1x Clear CMOS jumper, Wi-Fi / Bluetooth, 2.5G LAN Port, HD Audio Connectors, Flash BIOS Button, Optical S/PDIF OUT, 8 mounting holes, WIRELESS LAN & BLUETOOTH: Intel Wi-Fi 6 AX200, Bluetooth 5.1, Warranty – 3 Year
